WEIPU IP67 - SMALL SF10 METAL SERIES WITH PUSH-PULL LOCKING

  • ic_01-1

    Water tight

  • ic_01-2

    Dust proof

  • High mating cycles

    Quick connection

  • International standard_European configuration _Various configuration options

    Brass made

SF10 series is made of brass with chrome plating, specially designed for applications that require fast connection and easy grasp.
1) small size
2) 2-5 contacts
3) rated current: 3A & 5A
4) gold plating pin
5) IP67 after mated



Applications: This connector is designed with a fantastic appearance. The stunning brass-made shell made it widely used in many areas, such as medical devices, beauty equipment, testing or measuring equipment, communications field, etc.



Download SF10 Catalogue

5. SF10 Series (Push-pull)(waterproof)
  • 5. SF10
    SF10 Mating Diagram
  • SF6_SF8_SF10_SF12_SF16_SF20產品

Different
connector types

Available in both male and female.
Have options for plug, inline cable connector, panel socket.

SF series Case- Rail Adapter Design

For the application of rail adapter, ensuring the correct and secure connection is the priority. Thus, it is important to choose a solid, high-quality connector to keep a stable connection. Meanwhile, a connector with a push-pull design can also make it easier to use when switching the mode between plugging and unplugging.

READ MORE

Having questions for SF10?

INFO@WEIPUCONNECTOR.COM

+0086 021-56631111

Connect with WEIPU

  • SF1010 2D

    SF1010 2D

  • SF1011 2D

    SF1011 2D

  • SF1012 2D

    SF1012 2D

  • SF1015 2D

    SF1015 2D

  • Solder Spec

    • SF10 solder
