WEIPU IP67 WH400A Single-Pole Power Connector Plastic waterproof single-pole connectors with bayonet locking

Ｗater tight
Robust housing
International standard GB/T 11918.1-2014

WEIPU WH400A IP67 Series is a 400A heavy-duty single-pole power connector built for high-current power transmission in outdoor and harsh industrial environments. It combines an IP67 waterproof rating with a bayonet-locking coupling to deliver a fast, secure connection that stays stable under vibration.

Designed for safety and long service life, the WH400A uses a rugged, flame-retardant (UL94-V0) housing and color-coded, mechanically keyed alignment to prevent incorrect mating and reduce installation errors. Silver-plated brass contacts help minimize contact resistance, support consistent conductivity, and improve corrosion durability.

Key features

400A high current rating for demanding power applications
IP67 waterproof protection for outdoor and harsh environments
Bayonet-locking structure for fast, secure, and vibration-resistant connection
Silver-plated brass contacts for low resistance and long service life
Color-coded & mechanically keyed design to prevent phase mismatch
Operating temperature: −25°C to +85°C
UL94-V0 flame-retardant housing
GB/T 11918.1-2014 for international compatibility

Applications:

Ideal for industrial power distribution, temporary power systems, EV charging infrastructure, energy storage (ESS), stage lighting power, and other high-current waterproof connector applications where reliability and safety are critical.

Download Catalogue

Mating Diagram

Different types available

Reliable and robust solutions for high-current power connections in industrial, commercial, and outdoor applications
WH400A-TJ, WH400A-ZK, WH400A-TK, WH400A-ZJ

CEE Connector Case-Beijing National Stadium

WEIPU CEE connectors have been applied in the Beijing National Stadium since the 2008 Summer Olympics. The connectors were able to withstand the high demands of the project, including high voltages and currents, and harsh environmental conditions.
