WEIPU INDOOR USE CONNECTOR Plastic & Metal shell connectors with quick bayonet connection

  • Easy installation

    Indoor use

  • ic_01-4

    High performance materials

  • Fast-lock

    Flat pin

  • Anti-vibration

    Vibration resistant

WEIPU WT29 series connectors are made of durable, high-performance plastic and metal material body, which are used widely used for connecting LED lighting drives and industrial applications. The connectors are used for cable to panel-mount connections, with 3-pin and 5-pin configurations.


* Indoor use
* 3&5 contacts * Rated current 10A
* Termination: Solder
* Corrosion resistance materials
* Silver Plated Brass contacts
* Temperature ranges from –40°C to +85°C
* Cable OD ranges: 5mm – 9mm
* Vibration Resistant


Download WT29 Catalogue

36. WT29 Series (Bayonet)
  • 36. WT29
    WT29 Mating Diagram

Having questions for WT29?


+0086 021-56631111

Connect with WEIPU

  • WT29JT 2D

    WT29JT 2D

  • WT29K3Z 2D_2

    WT29K3Z 2D_2

  • WT29K5Z 2D

    WT29K5Z 2D

  • WT29Z 2D_1

    WT29Z 2D_1

  • WT29Z 2D_2

    WT29Z 2D_2

  • WT29Z 2D_3

    WT29Z 2D_3

  • WT29Z 2D_4

    WT29Z 2D_4
