WEIPU IP67-Medium SY17 NYLON SERIES WITH BAYONET COUPLING

Medium size
Water tight- IP67
Quick connecting
UL Certificated

SY17 series is a medium-size IP67 waterproof circular connector with bayonet coupling, designed for reliable power/signal connections in harsh outdoor and industrial environments.

Key Features

Medium-size design
1–10 contacts
Rated current: 5–50A
Gold-plated contacts for stable conductivity
Bayonet coupling for fast, secure mating
IP67 protection when mated
Cable assembly available
UL certified
Termination options: solder/crimp

Applications: This connector is designed for space-consuming and harsh environments. It is widely used in many areas, such as outdoor testing or measuring equipment, communications fields, outdoor lighting, etc. Its strong industrial design enables it to support many harsh and humid environments. It is available in solder and crimp termination for different contact arrangements.
